gefran SM32

63-F
—————— NOTICE D‘INSTRUCTIONS ——————
5. DIMENSIONS DU CONVERTISSEUR
F
C
D
Form 2
A
E
A
C
F
E
B
D
B
Form 1
Converter
SM32-480-185
SM32-480-280
SM32-480-420
SM32-480-650
SM32-480-1050
SM32-480-1500
SM32-480-2000
Form
(P. Degree)
1
(IP20)
2
(IP20)
3 (IP00)
A
[mm]
311
311
311
311
525
551
500
B
[mm]
388
388
388
388
554
686
855
C
[mm]
270
270
270
305
343
380
420
D
[mm]
375
375
375
375
200
200
225
E
[mm]
275
275
275
275
500
526
480
F
Ø
M6
M6
M6
M6
M6
M8
11
Weight
[kg]
18
26
30
31
63
85
75
