5 VDL200 Commissioning
This chapter explaines the corispondence of the parameters in AGy-L and the ones in VDL200. If the parameter in AGy-L are not
retrievable anylonger, set directly the VDL200 parameters based on the data available (speed, motor data, encoder etc…).
5.1 Set motor parameters in STARTUP WIZARD menu
Copy AGy-L PAR into
VDL200 PAR
AGy-L
VDL200
S.100 PAR 2000
S.150 PAR 2002
S.101 PAR 2004
S.001 PAR 2006
S.151 PAR 2008
not
available
(*)
PAR 2010
S.152 PAR 2012
(*) Set the value reported on the plate of the motor into VDL200 PAR: 2010.
03 STARTUP WIZARD
Set motor data?
E=Yes Down=Next
E
SEQ
01 PAR: 2000
Rated voltage
400
V
Def: 400
E
SEQ
01 PAR: 2000
Rated voltage
000000400 v
Def: 400
401 V
399 V
E

SEQ
02 PAR: 2002
Rated current
11.8 A
Def: 11.8
E
SEQ
02 PAR: 2002
Rated current
00000011.8 A
Def: 11.8
11.9 A
11.7 A
E

SEQ
03 PAR: 2004
Rated speed
1450 r
p
m
Def: 1450
E
SEQ
03 PAR: 2004
Rated speed
0000001450 r
p
m
Def: 1450
1451 rpm
1449 rpm
E

SEQ
04 PAR: 2006
Rated frequency
50 Hz
Def: 50
E
SEQ
04 PAR: 2006
Rated frequency
000000050 Hz
Def: 50
51 Hz
49 Hz
E

SEQ
05 PAR: 2008
Pole pairs
2
Def: 2
E
SEQ
05 PAR: 2008
Pole pairs
2
Def: 2
3
1
E

SEQ
06 PAR: 2010
Rated power
5.50 kW
Def: 5.50
E
SEQ
06 PAR: 2010
Rated power
0000005.50 kW
Def: 5.50
5.51 kW
5.49 kW
E

SEQ
07 PAR: 2012
Rated power factor
0.83
Def: 0.83
E
SEQ
07 PAR: 2012
Rated power factor
0.83
Def: 0.83
0.84
0.82
E
