SL5625 - CHASSIS, FUEL TANK, GRILLE AND COVERS
PRINTED IN U.S.A.
9
907221/BP0698
SN 8565 AND LATER (H/F), SN 8868 AND LATER (T-BAR)
a) Before SN 9548.
b) SN 9548 and later.
c) SN 9051 and later.
d) SN 10406 and later.
e) Before SN 10406.
Continued on next page
Ref Part Quantity
No. No. Description 5625
1 REF CHASSIS 1
2 088230 PLATE/FLOOR 1
650495 CS 1/2 X 1-1/4 (L, P) 2
3 078595 COVER/ACCESS 2
651168 TFS 3/8 X 3/4 24
4 046022 BOLT/WHEEL 32
5
128909
WASHER 32
6 113495 STOP/LIFTARM 2
071706 1/2 LN (2P) 4
7 113496 SHIM/LIFTARM 0.598 INCH AR
113497 SHIM/LIFTARM 0.125 INCH AR
8 075308 STRIP/BOLT 1
650448 CS 1/4 X 3/4 (NILN) 5
9 080072 FLAP/RUBBER 1
10 127596 FILLER/CHASSIS 2
650487 CS 5/16 X 1 (2P, NILN) 4
11 123816 PLUG/HOLE 1
12 123847 COVER/RT 1
650545 CS 5/16 X 1-1/4 (2P, NILN) 2
13 123664 COVER/LT 1
650545 CS 5/16 X 1-1/4 (2P, NILN) 2
14 123700 COVER/RT 1
650486 CS 5/16 X 3/4 (L, P) 2
15 123693 COVER/FOOT CONTROLS 1
650486 CS 5/16 X 3/4 (L, P) 2
067847 3/8 NILN (P) 2
16 121743 COVER/RT 1
650486 CS 5/16 X 3/4 (L, P) 2
17 127310 FLOOR ASSEMBLY 1
650486 CS 5/16 X 3/4 (L, P) 4
067847 3/8 NILN (P) 2
18 123691 PLATE/PUMP COVER 1
651168 TFS 3/8 X 3/4 2
19 121745 COVER/LT 1
650486 CS 5/16 X 3/4 (L, P) 2
20 650916 NIPPLE/PIPE 1/2 X 2-1/2 1
21 660027 COUPLING/PIPE 1/2 1
22 660046 BUSHING/HEX REDUCER 1/2 X 3/8 1
23 128591 BREATHER/RESERVOIR 1
24 127342 CAP/HYDRAULIC RESERVOIR 1
25
123964
e
COVER/HYDRAULIC TANK 1
130021
d
COVER/HYDRAULIC TANK 1
650934 TFS 3/8 X 1 8
26
096236
e
WINDOW/OIL LEVEL 1
130006
d
WINDOW/OIL LEVEL 1
27 660080 PLUG/PIPE 1
28 650576 PLUG/PIPE 1
29 057569 PLUG/PIPE MAGNETIC 1
30 079339 BRACE/TANK 1
650704 CB 3/8 X 1 1
070856 FLANGED LOCK NUT 1
31 073115 GUARD/SPILL 1
650293 TFS #10 X 3/8 2
