SL5625 - AXLES, DRIVE CHAINS & RELATED COMPONENTS
PRINTED IN U.S.A.
17
907221/BP0698
a) For service, see pages titled “Hydraulic Components”.
b) Short chain for left front or right rear.
c) Long chain for left rear or right front.
d) SN 10334 and later.
e) Before SN 10334.
Ref Part Quantity
No. No. Description 5625
1
078961
a
GEARCASE/ASSY PLANETARY 2
651211 CS 3/8 NFX 3-1/2 GRADE 8 (L) 24
2 078962 RING/RETAINING 2
3 078945 BEARING/CONE 8
4 078946 BEARING/CUP 8
5 087816 ADAPTOR/PLANETARY 2
651330 PLUG/PIPE 3/8 HEX 2
651085 CS 1/2 NF X 1-3/4 GRADE 8 22
064373 NILN 1/2 NF 22
6 520013 BEARING/CUP 4
7 083108 BEARING/CONE 4
8 087813 SEAL/OIL 6
9 088204 PLATE/IDLER 4
653119 NUT/CASTELLATED 3/4 NF 4
079209 NILN 3/4 4
655018 PIN/COTTER 3/16 X 1-1/4 4
10
087817
SHAFT/PLANETARY ASSEMBLY (18 TOOTH SPROCKET) 2
11 088943 ROD/TENSIONER ASSEMBLY 4
653021
e
NUT 5/8 8
129311
e
NUT/HEX LOCK 8
653021
d
NUT 5/8 4
129056
d
NUT/SPIRALOCK 5/8 8
H8353A WASHER/SPECIAL 8
12 041885 CONE/BEARING (IDLER) 8
13 041884 CUP/BEARING (IDLER) 8
14 078955 SPROCKET/IDLER ASSEMBLY 14T 4
15 078949 WASHER 4
16 123739 SPROCKET/ASSY 39T 4
17 087811 WASHER/SPACER 4
18 087812 WASHER/SHIM AR
19 087809 ADAPTOR/WHEEL 4
129055 NUT/SPIRALOCK 1/2 32
20 133957 BOLT/WHEEL 5/8 X 2 32
21 133909 AXLE/ASSEMBLED 4
650964 NUT/CASTELLATED 1-1/4 NF 4
650554 PIN/COTTER 1/4 X 2-1/4 4
22 131083 WHEEL 15 X 6 LB 4
122978 WHEEL 15 X 13 4
122976 WHEEL 16-1/2 X 9-3/4 4
23 128507 STEM/VALVE SHORT 4
24 079152 NUT/WHEEL 32
25 088209 TUBE/INNER 4
26 088201 IDLER/ASSY LT FRONT 1
650912 CS 3/4 X 7 (2P, NILN) 1
27 088203 IDLER/ASSEMBLY LT REAR 1
650912 CS 3/4 X 7 (2P, NILN) 1
28 088200 IDLER/ASSEMBLY RT FRONT 1
650912 CS 3/4 X 7 (2P, NILN) 1
29 088202 IDLER/ASSEMBLY RT REAR 1
650912 CS 3/4 X 7 (2P, NILN) 1
30
087831
b
CHAIN/ROLLER (#80HE) 62 LINKS W/CONNECTOR 080305 2
31
087832
c
CHAIN/ROLLER (#80HE) 76 LINKS W/CONNECTOR 080305 2
