SL5625 - ROPS, SEAT & ENGINE COVER
PRINTED IN U.S.A.
19
907221/BP0698
a) SN 9117 and later.
b) Before SN 9117.
c) Before SN 9798.
d) SN 9798 and later.
e) Before SN 8238.
f) SN 10636 and later.
g) Before SN 10636.
Ref Part Quantity
No. No. Description 5625
1 087896 WINDOW/CAB REAR 1
2 087897 WEATHERSTRIP/WINDOW 1
3 122484 SPRING/GAS 1
4 122485 STUD/BALL 2
071701 5/16 LOCK NUT 2
5 129636 COVER/ENGINE 1
650535 CS 3/8 X 2-1/4 (NILN) 2
6 074860 STEM/RUBBER 2
7 089010 STUD/BALL 2
071701 5/16 LOCK NUT 2
8 089012 CLIP/SPRING 2
9 089009 SPRING/GAS 2
10
127801
a
ROPS/ASSEMBLY 1
650354 CS 5/8 X 4-1/2 (NILN) 2
088979
b
ROPS/ASSEMBLY 1
650354 CS 5/8 X 4-1/2 (NILN) 2
11
121713
g
SEAT/ASSEMBLY (INCLUDES ITEMS 13 & 14) 1
653007 5/16 NUT (L) 4
130085
f
SEAT/ASSEMBLY (INCLUDES ITEMS 13 & 14) 1
12
121412
BELT/SEAT 1
13 123624 SLIDE/SEAT LEFT (WITH ADJUSTER) 1
14 123625 SLIDE/SEAT RIGHT (WITHOUT ADJUSTER) 1
15 067750 NUT/SPEED 1
16
121946
a
FILLER/ROPS 1
651307 SCREW/PAN HEAD PHILLIPS 1/4 X 1/2 3
088915
b
FILLER/ROPS 1
651307 SCREW/PAN HEAD PHILLIPS 1/4 X 1/2 3
17 057557 WASHER 6
18 064543 MOUNT/ISOLATION 2
650850 CS 1/2 X 2-3/4 (NILN) 2
19
078580
c
POUCH/MANUAL 1
20
078581
c
RIVET/BLIND 4
21 052046 PLUG/PLASTIC 4
22 127435 SPRING/EXTENSION 1
650491 CS 3/8 X 1-1/4 (2N) 1
23 091098 LINK/LIMIT 1
24 091057 LINK/LIMIT ASSEMBLY 1
654009 1/2 FLAT WASHER 5
655006 PIN/COTTER 2
25
129361
d
CASE/OPERATORS MANUAL 1
650771 CB 1/4-20 X 1/2 GR5 PL (NILN, FW) 4
26
078732
e
SLEEVE/PLASTIC SEAT BELT 2
650944 THMS 1/4 X 5/8 (NILN) 2
27
078733
e
SPRING/RETAINER 2
650495 CS 1/2 X 1-1/4 (NILN) 2
