SL5625 - RADIATOR AND HYDRAULIC OIL COOLER
PRINTED IN U.S.A.
43
907221/BP0698
SN 9764 AND LATER
Ref Part Quantity
No. No. Description 5625SX 5625DX
1 127444 SPACER/FAN (USED WITH METAL FAN (123285)) 1 -
127525 SPACER/FAN (USED WITH PLASTIC FAN (127494)) 1 -
2 123285 FAN/METAL 15” 1-
656003 CS M8 X 40 (5/16 L) 4-
127494 FAN/PLASTIC 15” 1-
656130 CS M8 X 50 4-
3 088912 WASHER/SPECIAL 22
067847 3/8 NILN 22
4 123986 BRACE/RADIATOR RT 11
5 072384 MOUNT/ISOLATOR 22
6 127430 SHROUD/FAN 15” 1-
650485 CS 5/16 X 5/8 (L, P) 4-
7 057067 PLUG/HOLE 11
8 127556 SEAL/SHROUD 22
9 123987 BRACE/RADIATOR LT 11
10 055030 CLAMP/HOSE 44
11 124015 HOSE/LOWER RADIATOR 1 1
12 123946 HOSE/UPPER RADIATOR 1 1
13 127302 SUPPORT/RADIATOR 11
650490 CS 3/8 X 1 (NILN, P) 44
14 127607 MOUNT/RADIATOR RT 11
650533 CS 3/8 X 1-1/2 (NILN, 2P) 2 2
15 127608 MOUNT/RADIATOR LT 11
650533 CS 3/8 X 1-1/2 (NILN, 2P) 2 2
16 058615 CLAMP/HOSE 33
17 087840 RADIATOR (INCLUDES ITEMS 18 & 20) 1 1
068034 1/2 NILN (P) 22
18 129346 DRAIN/COCK 11
19 127505 HOSE/DRAIN 11
20 079010 CAP/RADIATOR 11
21 129059 SUPPORT/COOLER 11
650485 CS 5/16 X 5/8 (L, P) 22
22 128816 PLATE/RADIATOR 11
650485 CS 5/16 X 5/8 (L) 22
23 128815 PLATE/HINGE 11
650485 CS 5/16 X 5/8 (L, P) 22
24 078921 COOLER/OIL 1-
25 078922 MOUNT/ELASTOMER 44
650449 CS 1/4 X 2-1/2 (NILN, 2P) 4 4
26 127497 SEAL/SHROUD 11
27 123765 SEAL/SHROUD 33
28 128806 SHROUD/COOLER 11
29 129418 SEAL/SHROUD 22
30 129120 LATCH/FLEXIBLE 11
651312 THMS #10-24 X 1/2 (L) 33
31 127725 COOLER/OIL -1
32 127525 SPACER/FAN -1
656130 CS M8 X 50 -4
33 127495 FAN/PLASTIC 17” -1
656130 CS M8 X 50 (5/16, L) -4
34 124090 SHROUD/FAN 17” -1
650485 CS 5/16 X 5/8 (L, P) -4
35 128182 RADIATOR (INCLUDES ITEMS 18 & 20) - 1
068034 1/2 NILN (P) -2
To Next Page
