SL5625 - RADIATOR AND HYDRAULIC OIL COOLER
PRINTED IN U.S.A.
45
907221/BP0698
SN 9051 THROUGH SN 9763
a) SN 9086 and later.
b) Before SN 9086.
c) Used on DX units before SN 9086, and on all SX models SN 9051 through SN 9763.
Ref Part Quantity
No. No. Description 5625SX 5625DX
1
127444
c
SPACER/FAN 11
2 123285 FAN/METAL 15” 1-
656002 CS M8 X 35 (5/16 L) 4-
3 088912 WASHER/SPECIAL 22
067847 3/8 NILN 22
4 123986 BRACE/RADIATOR RT 11
5 072384 MOUNT/ISOLATOR 22
6 127430 SHROUD/FAN 15” 1-
650485 CS 5/16 X 5/8 (L, P) 4-
7 057067 PLUG/HOLE 11
8 127556 SEAL/SHROUD 22
9 123987 BRACE/RADIATOR LT 11
10 055030 CLAMP/HOSE 44
11 124015 HOSE/LOWER RADIATOR 1 1
12 123946 HOSE/UPPER RADIATOR 1 1
13 127302 SUPPORT/RADIATOR 11
650490 CS 3/8 X 1 (NILN, P) 44
14 127607 MOUNT/RADIATOR RT 11
650533 CS 3/8 X 1-1/2 (NILN, 2P) 2 2
15 127608 MOUNT/RADIATOR LT 11
650533 CS 3/8 X 1-1/2 (NILN, 2P) 2 2
16 058615 CLAMP/HOSE 33
17 087840 RADIATOR (INCLUDES ITEMS 18 & 20) 1 -
068034 1/2 NILN (P) 2-
18 129346 DRAIN/COCK 11
19 127505 HOSE/DRAIN 11
20 079010 CAP/RADIATOR 11
21 090926 BRACKET/COOLER RT 1-
650484 CS 5/16 X 1/2 (L, P) 22
22 090924 BRACKET/COOLER LT 11
650486 CS 5/16 X 3/4 (L) 22
23 078922 MOUNT/ELASTOMER 44
650449 CS 1/4 X 2-1/2 (NILN, 2P) 4 4
24 078921 COOLER/OIL 1-
25 127496 SEAL/SHROUD 33
26 127305 SHROUD/COOLER 1-
650485 CS 5/16 X 5/8 (L, P) 4-
27 127497 SEAL/SHROUD 33
28 127750 CLAMP/SPRING 11
29
127525
a
SPACER/FAN -1
30
127495
a
FAN/PLASTIC 17” -1
656130 CS M8 X 50 (5/16 L) -4
123926
b
FAN/METAL 17” -1
656130 CS M8 X 50 (5/16 L) -1
31 124090 SHROUD/FAN 17” -1
650485 CS 5/16 X 5/8 (L, P) -4
32 128182 RADIATOR (INCLUDES ITEMS 18 & 20) - 1
068034 1/2 NILN (P) -2
33 127888 BRACKET/COOLER RT -1
650484 CS 5/16 X 1/2 (L, P) -2
34 128196 BAR/SPACER -1
35 127725 COOLER/OIL -1
36 127889 SHROUD/COOLER -1
650485 CS 5/16 X 5/8 (L, P) -4
