SL5625 - FRAME MOUNTED FRONT HYDRAULICS
PRINTED IN U.S.A.
61
907221/BP0698
Ref Part Quantity
No. No. Description 5625
804558 FRONT HYDRAULIC LINES KIT (FIELD INSTALLED) - ASSEMBLY CONSISTS OF: 1
1 088959 TUBE/DRAIN 1
2 079115 TEE/UNION 2
3 088957 TUBE/RIGHT 1
4 089082 CUSHION/SINGLE 3/4 TUBE 4
5 056085 NUT/JIC CAP 1-1/16-12 2
6 089083 PLATE 10
650733 CS 5/16 X 2-1/2 4
7 074282 TEE/SWIVEL 2
8 088956 TUBE/FRONT 2
9 066580 FITTING/MALE CONNECTOR 2
10 056429 VALVE/SHUT-OFF 1
11 054856 ADAPTER/90 DEGREE 2
12 079418 PLUG/DUST 1
13 079253 COUPLER/QUICK DISCONNECT 1
14 079254 NIPPLE/QUICK DISCONNECT 1
15 079417 CAP/DUST 1
16 088962 TUBE/LEFT 1
17 091036 TUBE/POWER BEYOND 1
To Next Page
