Gehl 5625 - Page 65

SL5625 - HYDROSTATIC SYSTEM
PRINTED IN U.S.A.
63
907221/BP0698
SN 8868 AND LATER
a) For Seal Kit, order P/N 121187.
b) For breakdown, see pages titled “Hydraulic Components”.
c) Before SN 8966.
d) SN 8966 and later.
e) Before SN 8966. Also uses one adjacent elbow/90 degree, P/N 088117, not shown.
f) Used on all SX units and on DX units before SN 9117.
g) Used on DX units SN 9117 and later.
h) SN 10506 and later.
i) Before SN 10506.
Continued on next page
Ref Part Quantity
No. No. Description 5625
1 089095 HOSE/ASSEMBLY 3/8 X 17 4
2 055981 TEE/MALE 1
3 067761 ELBOW/MALE 90 DEGREE 3
4 127406 CLIP/TUBE 1
5
079965
e
FITTING/90 DEGREE 1
121684
d
FITTING/90 DEGREE 1
6
087215
ab
CONTROL/BOOST 2
650818 CS 3/8 X 3 (NILN, P) 2
7 091059 HOSE/ASSEMBLY 1/2 X 27 1
8 062889 ADAPTER/STEEL PIPE 1
9 068938 ELBOW/90 DEGREE ADJUSTABLE 2
10 091060 HOSE/ASSEMBLY 1/2 X 16 1
11
087985
c
HOSE/ASSEMBLY 1 X 48 2
121050
d
HOSE/ASSEMBLY 3/4 X 24 2
12
079029
c
ELBOW/45 DEGREE 3
121773
d
ELBOW/45 DEGREE 3
13
121684
d
FITTING/90 DEGREE 3
077965
c
FITTING/90 DEGREE 3
14
079034
b
MOTOR/DRIVE 2
650495 CS 1/2 X 1-1/4 (L) 4
15
054783
i
GASKET/MOTOR 2
079289
h
O-RING 2
16
079033
c
HOSE/ASSEMBLY 1 X 34-1/2 WITH 90 DEGREE ELBOW 1
121050
d
HOSE/ASSEMBLY 3/4 X 24 1
17 073411 CONNECTOR/MALE 2
18
064644
c
CONNECTOR/MALE 37 DEGREE 1
121773
d
ELBOW/45 DEGREE 1
19 088912 WASHER/SPECIAL 2
20 078831 BRACKET/ISOLATOR 1
650487 CS 5/16 X 1 (NILN, 4P) 2
21 072384 ISOLATOR/RUBBER 1
650528 CS 3/8 X 2 (NILN) 1
22 088929 SUPPORT/PUMP 1
650495 CS 1/2 X 1-1/4 (N) 2
23 091017 TUBE/PUMP DRAIN 1
24 075503 HOSE/ASSEMBLY 3/4 X 24 1
25 088120 TEE/TAPPED 1
