SL5625 - TRACTION CONTROLS (T-BAR)
PRINTED IN U.S.A.
69
907221/BP0698
a) SN 8868 and later.
b) Before SN 8868.
c) SN 9629 and later.
d) Before SN 9629.
e) SN 8544 and later.
f) SN 9428 and later.
g) Before SN 9428.
h) SN 11109 and later.
i) SN 9428 through SN 11109.
Continued on next page
Ref Part Quantity
No. No. Description 5625
1 088946 HANDLE/CONTROL 1
050270 PIN/ROLL 1
2 074093 BOOT/RUBBER 1
3
121578
a
BRACKET/TRUNNION RT 1
650486 CS 5/16 X 3/4 (NILN) 2
088251
b
BRACKET/TRUNNION RT 1
650487 CS 5/16 X 1 (L) 2
4
063718
a
SPACER 1
650733 CS 5/16 X 2-1/2 (NILN) 2
063718
b
SPACER 2
650773 CS 5/16 X 2-1/2 (NILN) 4
5 065057 BEARING/NEEDLE 2
6 056937 WASHER AR
7
121013
g
LEVER/PIVOT ASSEMBLY 1
075288 PIN/ROLL 1
128944
i
LEVER/PIVOT ASSEMBLY 1
075288 PIN/ROLL 1
131848
h
LEVER/PIVOT ASSEMBLY 1
8 079216 END/ROD 4
651062 5/16NF NUT (P,L) 4
9 060505 BEARING/NEEDLE 2
10
123280
a
BRACKET/TRUNNION LT 1
650486 CS 5/16 X 3/4 (NILN) 1
088251
b
BRACKET/TRUNNION LT 1
650487 CS 5/16 X 1 (L) 2
11
123722
a
ROD/TAKE UP 2
653039 5/16NF JAM NUT 4
079217
b
ROD/TAKE UP 2
653039 5/16NF JAM NUT 4
12 060508 TRUNNION 1
076002 ZERK/GREASE 1
13 127360 BUSHING AR
14 088239 ARM/PIVOT 1
075288 PIN/ROLL 1
15
128892
c
BRACKET/BEARING 2
650487 CS 5/16 X 1 (NILN) 4
078990
d
BRACKET/BEARING 2
650487 CS 5/16 X 1 (NILN) 4
