Gehl 5625 User Manual

SL5625 - LIFT/TILT CONTROLS (T-BAR)
PRINTED IN U.S.A.
75
907221/BP0698
a) SN 8868 and later.
b) Before SN 8868.
Ref Part Quantity
No. No. Description 5625
1 088946 HANDLE/CONTROL 1
050270 PIN/ROLL 1
2 074093 BOOT/RUBBER 1
3 056937 WASHER AR
4 065057 BEARING/NEEDLE 2
5
123280
a
BRACKET/TRUNNION LT 1
650486 CS 5/16 X 3/4 (NILN) 2
088251
b
BRACKET/TRUNNION LT 1
650487 CS 5/16 X 1 (L) 2
6
124067
a
ROD/LIFT CONTROL 1
653039 3/8 NF JAM NUT 1
088253
b
ROD/LIFT CONTROL 1
653039 3/8 NF JAM NUT 1
7 079068 ARM/TILT CONTROL 1
8 127488 PIN 4
650551 PIN/COTTER 4
9
123723
a
ROD/TILT CONTROL 1
653039 3/8 NF JAM NUT 1
088252
b
ROD/TILT CONTROL 1
653039 3/8 NF JAM NUT 1
10 054202 JOINT/BALL 1
064840 3/8 NF NILN 1
11 079039 JOINT/BALL 1
067847 3/8 NILN 1
12 074868 SPACER 1
13 088249 TAB/TILT 1
075288 PIN/ROLL 1
14 060508 TRUNNION 1
076002 ZERK/GREASE 1
15 060505 BEARING/ROLLER 1
16
063718
a
SPACER 1
650733 CS 5/16 X 2-1/2 (NILN) 1
063718
b
SPACER 2
650733 CS 5/16 X 2-1/2 (NILN) 2
17
121578
a
BRACKET/TRUNNION RT 1
650486 CS 5/16 X 3/4 (NILN) 2
088251
b
BRACKET/TRUNNION RT 1
650487 CS 5/16 X 1 (L) 2
18 113472 NUT/SPRING 2
