SL5625 - LIFT/TILT HYDRAULICS
PRINTED IN U.S.A.
81
907221/BP0698
a) For breakdown, see Self-Leveling Valves under pages titled “Hydraulic Components”.
b) Before SN 8868 on units equipped with T-Bar controls.
c) SN 8565 and later on units with Hand/Foot control. SN 8868 and later on all units.
d) SN 8565 and later.
e) Before SN 8565.
f) SN 9728 and later.
g) Before SN 9728.
Continued on next page
Ref Part Quantity
No. No. Description 5625
1 087987 HOSE ASSEMBLY 5/8 X 33 2
2 088281 TUBE/TILT REAR 1
3 088282 TUBE/TILT FRONT 1
4 079098 PLATE/TWIN COVER 5
650449 CS 1/4 X 2-1/2 (NILN, P) 1
650979 CS 1/4 X 3-1/4 (NILN, P) 2
064260 5/16 NILN 2
5 079126 CLAMP/TUBE DOUBLE 5/8 (1 PAIR) 3
6
065415
ELBOW/90 DEGREE SWIVEL 1
7
072807
b
TEE/MALE RUN STR THD 37 1
072807
c
TEE/MALE RUN STR THD 37 2
8 091096 STRAP/TIE 1
650449 CS 1/4 X 2-1/2 (NILN) 2
9
088044
b
TEE/FITTING BRANCH 1
10
088279
TUBE/TILT SPOOL “C” TO SELF LEVEL VALVE “D” 1
11
088280
b
TUBE/TILT SPOOL “F” TO SELF LEVEL VALVE “C” 1
12 091018 TUBE/LIFT SPOOL “E” TO SELF LEVEL VALVE “B” 1
13
072580
b
CONNECTOR 4
072580
c
CONNECTOR 5
14 067761 ELBOW/EXT 90 DEGREE 2
15
087274
ag
VALVE ASSEMBLY SELF-LEVEL 1
652040 CB 5/16 X 2-1/2 (NILN) 2
128844
af
VALVE ASSEMBLY SELF-LEVEL 1
16 087988 HOSE ASSEMBLY 3/8 X 18 4
17 087948 PIN/LIFT CYLINDER REAR 2
650547 CS 5/16 X 3-1/2 (NILN) 2
18 088937 CLAMP 2
19 088273 TUBE/LIFT CYLINDER OUTER 2
20 089099 FITTING/ADAPTOR 4
21 REF CYLINDER/LIFT - SEE PAGES TITLED “HYDRAULIC COMPONENTS” 2
570005 FITTING/GREASE 90 DEGREE 2
570002 FITTING/GREASE SHORT 2
22
127620
d
PIN/LIFT CYLINDER FRONT 2
650733 CS 5/16 X 2-1/2 (NILN) 2
087990
e
PIN/LIFT CYLINDER FRONT (NOT SHOWN) 2
650487 CS 5/16 X 1 (NILN) 2
23 088275 TUBE/LIFT CYLINDER ROD END RIGHT 1
24 088904 CLAMP/TUBE DOUBLE 1/2 (1 PAIR) 2
25 089098 SPACER 2
