SL5625 - LIFT/TILT HYDRAULICS
PRINTED IN U.S.A.
83
907221/BP0698
a) For breakdown, see Solenoid Valves under pages titled “Hydraulic Components”.
b) Before SN 8868 on units equipped with T-Bar controls.
c) SN 8565 and later on units with Hand/Foot control. SN 8868 and later on all units.
d) SN 8565 and later.
e) Before SN 8565.
f) SN 9728 and later.
g) Before SN 9728.
Ref Part Quantity
No. No. Description 5625
26 091011 TUBE/LIFT CYLINDER REAR RIGHT 1
27 091010 TUBE/SL VALVE CROSSOVER 1
28 091012 TUBE/LIFT REAR LEFT 1
29 091013 TUBE/LIFT CYLINDER FRONT RIGHT 1
30 091009 TUBE/LIFT SPOOL “B” TO SOLENOID 1
31 122896 CONNECTOR SWIVEL 1
32
REF
VALVE/SOLENOID - SEE PAGES TITLED “HYDRAULIC COMPONENTS”
33 088105 TUBE/TILT CYLINDER OUTER 1
34
089099
c
FITTING/ADAPTOR 1
088046
b
FITTING/ADAPTOR 1
35 088935 TEE/MALE STR-SWIVEL INT STR 1
36 091014 TUBE/LIFT FRONT LEFT 1
37 088274 TUBE/LIFT CYLINDER ROD END LEFT 1
38
REF
CYLINDER/TILT - SEE PAGES TITLED “HYDRAULIC COMPONENTS” 2
570005 FITTING/GREASE 90 DEGREE 4
39 079022 PIN/TILT CYLINDER 2
650733 CS 5/16 2-1/2 (NILN) 2
40 062397 ELBOW/45 DEGREE MALE 4
41
123725
c
PIN/TILT CYLINDER UPPER 2
540020 RETAINING RING 2
650733 CS 5/16 X 2-1/2 (NILN) 2
087993
b
PIN/TILT CYLINDER UPPER ASSEMBLY (NOT SHOWN) 2
064260 5/16 NILN (P) 2
42 128632 HOSE/ASSEMBLY 1/2 X 15 4
43 122649 CLAMP/TUBE 2
064260 5/16 NILN (P) 1
44 088104 TUBE/TILT CYLINDER INNER 1
45
072615
b
ELBOW 1
067761
c
ELBOW 1
46
127595
c
TUBE/TILT SPOOL “C” TO SELF LEVEL VALVE “D” 1
To Next Page
