SL5625 - LIFT ARM
PRINTED IN U.S.A.
89
907221/BP0698
a) SN 9051 and later.
b) Before SN 9051.
c) SN 9444 and later.
d) Before SN 9444.
e) SN 9146 and later.
f) Before SN 9146.
g) SN 11095 and later.
h) Before SN 11095.
Ref Part Quantity
No. No. Description 5625
1
123696
h
LIFT ARM (INCLUDES ITEMS 2 AND 3) 1
570005 ZERK/GREASE 2
131462
g
LIFT ARM (INCLUDES ITEMS 2 AND 3) 1
127783 PLATE/WELD 3
127968 PLATE/WELD 6
089076 3 STUD BRACKET 2
2 079204 BUSHING 8
3 088101 BUSHING 2
4 087947 PIN/PIVOT 2
650547 CS 5/16 X 3-1/2 (NILN) 2
5
123826
a
ARM/SAFETY 1
650483 CS 3/4 X 5-1/2 (NILN) 1
089060
b
ARM/SAFETY 1
650709 CS 3/4 X 4 (NILN) 1
6 089079 PIN/KLIK 1
7 074860 STEM/RUBBER 1
8 087854 PAD/ARM BRACE 1
9
128364
c
QUICK-TACH
™
SYSTEM
1
10
128368
c
HANDLE 1
650650 CS 1/2 X 3-1/2 (NILN) 1
11
121707
c
LINK/PIN 2
067847 3/8 NILN 2
654006 3/8 PLAIN WASHER 4
12 H8049 SPRING 2
13
114883
c
PIN/ATTACHING 2
650850 CS 1/2 X 2-3/4 (NILN, 2 P) 2
14
088092
d
QUICK-TACH
™
SYSTEM
1
15
079148
d
HANDLE 1
651017 CS 3/4 X 3-3/4 (NILN) 1
16
079142
d
ROD/SPRING ASSEMBLY 2
655016 PIN/COTTER 2
654009 1/2 PLAIN WASHER 4
17
073776
d
WASHER 2
18
079147
d
PIN/ATTACHING 2
650850 CS 1/2 X 2-3/4 (NILN, 2 P) 2
19 087997
PIN/QUICK-TACH
™
SYSTEM
2
650650 CS 1/2 X 3-1/2 (NILN) 2
20
9H240
f
CS SPECIAL (L) 2
21
128181
e
CAP/GREASE 2
22
570002
e
ZERK/GREASE 2
570014
f
ZERK/GREASE 2
23 065054 PIN/ROLL 2
24 088070 HUB/ARM ASSEMBLY RIGHT (INCLUDES ITEM 3) 1
25 088113 HUB/ARM ASSEMBLY LEFT (INCLUDES ITEM 3) 1
