7
6. Insert the end into the slot in the take-up reel and
wind two or three turns of paper around the reel
(See fig 3)
7. Load the take-up reel into the support
8. Press the ‘J’ feed key (See fig 4)
9. Close the printer cover
Removing the Paper Rolls
To remove the paper roll for the receipt
1. Open the printer cover
2. Push the platen release button (left)
3. Remove the roll
To remove the paper roll for the journal
1. Open the printer cover
2. Push the platen release button (right)
3. Cut the paper after the end of the printing
4. Remove the take-up spool from the support (See fig 5)
5. Remove the paper record for the take-up reel (See fig 6)
6. Install the remaining paper for the journal
7. Close the printer cover
Fig 4
Fig 5
Fig 6
