www.gemu-group.com 47 / 76 GEMÜ 1436 cPos
Menu levels Submenu Display Function Value range Default setting
Active
Error
Warning
AlarmMaxK2 Switch point that
switches after K2 is ex-
ceeded
0.2 ... 99.8 % 10.0 %
AlarmMinK2 Switch point that
switches after K2 is un-
dershot
0.2 ... 99.8 % 90.0 %
SSE2Time Delay time between error
detection and error mes-
sage to K2
0.1 to 100.0 s 5.0 s
ErrorTime Delay time between error
detection and error mes-
sage
0.5 ... 100 s 0.2 s
ErrorAction Function of the process
valve if there is an error
message
Close / Open / Hold /
Safe
Close
Warn. Time Delay time between de-
tection and output of
warning
0.0 ... 100.0 s 0.0 s
CpyParaSet Copies parameters to
various working memor-
ies (P1/P2/P3/P4)
AnalogOut Function of analogue
output
Poti / Ix Poti
4 SetCalibration X-Direction* Determines the direction
of the actual value signal
(rising/falling)
rise / fall rise
W-Direction Determines the direction
of the set value signal
(rising/falling)
rise / fall rise
W-Function The control character-
istic is defined
Lin./1:25/1:50/free lin.
Set W-free 10 control characteristic
points can be pro-
grammed as desired
W 0 % 0 ... 100 % 0.0 %
W 10 % 0 ... 100 % 10.0 %
W 20 % 0 ... 100 % 20.0 %
W 30 % 0 ... 100 % 30.0 %
W 40 % 0 ... 100 % 40.0 %
W 50 % 0 ... 100 % 50.0 %
W 60 % 0 ... 100 % 60.0 %
W 70 % 0 ... 100 % 70.0 %
W 80 % 0 ... 100 % 80.0 %
W 90 % 0 ... 100 % 90.0 %
W 100 % 0 ... 100 % 100.0 %
Y-Direction* Determines the direction
of the process controller
output (rising/falling)
rise / fall rise
OutMinPos Valve position at actual
value output signal
0/4mA
0 ... 100 % 0.0 %
16 Operation
