www.gemu-group.com 21 / 29 GEMÜ M75
1
2
3
4. Put new actuator 1 on valve body 3.
5. Tighten union nut 2 clockwise to tightening torque A.
Valve body
material
Tightening torque A
PVC-U 5
PVDF 5
PP-H 4
Torques in Nm
ü Depending on the version, the sealing plug with O-ring is
included with the product.
1
2
6. Screw sealing plug 1 with O-ring into actuator 2.
7. Tighten sealing plug 1 to tightening torque B.
Valve body
material
Tightening torque B
PVC-U 3
PVDF 3
PP-H 3
Torques in Nm
14.2 Cleaning the product
CAUTION
Foreign matter
▶ Damage to the valves.
● If the plant is new and after repairs, rinse the piping sys-
tem with the valves fully open.
ð The plant operator is responsible for selecting the clean-
ing material and performing the procedure.
• Clean the product with a damp cloth.
• Do not clean the product with a high pressure cleaning
device.
14 Inspection and maintenance
