5
The RP60/70 Presets
The RP60/70 contains 32 Internal Presets, consisting of Single,
Layered and Split sound combinations.
For model RP70, each sound combination recalls an appropri-
ate configuration of effects (Reverb and Chorus) together with
Volume and Balance settings.
For model RP60, a configuration of effects (Reverb and Chorus)
is recalled for the Grand Piano Preset only; for all other sound
combinations recalled by the Presets, the Reverb and Chorus
configurations can be activated by pressing both the SOUND/
DATA
m
/
n
buttons at the same time after powering up.
The table shown opposite lists the RP60/70 Presets. After each
name, the type of Preset is indicated in brackets: “S” for Single,
“L” for Layer and “Sp” for Split.
Using the SOUND/DATA
m
/
n
buttons, it is possible to select
the RP60/70 Presets sequentially.
1. After turning the RP60/70 on, press the DATA m button.
You will recall the first Preset, called Stage Piano which plays across the
entire keyboard.
2. Press the DATA m button again to recall the Preset,” Rock Piano”.
Every time you press the DATA
m
button, you will select the Presets
in increasing numerical order. When you reach the last Preset on the
list, Church/Choir, pressing the Data
m
button will have no effect.
3. Press the DATA n button.
If you started with the Preset Rock Piano selected in step 2 above, you
will return to the previous Preset “Stage Piano”.
Every time you press the DATA
n
button, you will select the Presets
in decreasing numerical order.
Once you select the first preset, “Stage Piano”, pressing the Data
n
button will have no effect.
4. To cancel the current Preset and return to the Grand Piano Preset, press
the Grand Piano button.
The Grand Piano button will always return to the Grand Piano Preset
active across the entire keyboard.
LED on
N
°
Name N
°
Name
1. Stage Piano (S) 17. Harpsi/Strings (L)
2. Rock Piano (S) 18. Vibes 2 (Sp)
3. Rhodex (S) 19. Rock Piano/Pad (L)
4. Hard Rhodex (S) 20. Rhodex Pad (L)
5. Wurtlitz (S) 21. FM Piano Stage (L)
6. FM Piano (S) 22. Strings/Choir (L)
7. El. Glock Piano (L) 23. Piano/Choir (L)
8. Harpsi (S) 24. Stage Piano/Poly (L)
9. Vibes 1 (S) 25. Rock Piano/Poly (L)
10. Piano/Strings (L) 26. Jazz Organ 1 (S)
11. Stage Piano/Strings (L) 27. Pop Organ (S)
12. Stage Piano/Bass (Sp) 28. Theatre Organ (S)
13. Piano/Bass (Sp) 29. Church Organ (L)
14. Rhodex/Ride (Sp) 30. Jazz Organ 2 (Sp)
15. FM Pad (L) 31. Organ/Bass (Sp)
16. FM/El.Bass (Sp) 32. Church/Choir (L)
