GEM-P3200 Programming Instructions
L
NAPCO Security Systems
WI818D 08/00
!
Page 36
SYSTEM DELAYS & TIMEOUTS (ADDRESS 2400, 2401, 2403-2405, 4082 & 4083)
DATA ENTRIES
LEFT RIGHT
blank (•) blank (•)
blank (•) 1
blank (•) 2
blank (•) 3
blank (•) 4
blank (•) 5
blank (•) 6
1 blank (•)
FF
DELAY/
TIMEOUT
0 min.
1 min.
2 min.
3 min.
4 min.
5 min.
6 min.
16 min.
255 min.
[Default = blank (•) blank (•)]
ADDRESS 2400
LEFT RIGHT
Reset
Output
Timeout
(min.)
[Default = blank (•) blank (•) ]
ADDRESS 2401
LEFT RIGHT
Aux.
Output
Timeout
(min.)
[Default = 1 blank (•)]
ADDRESS 2403
LEFT RIGHT
Burg.
Alarm
Output
Timeout
(min.)
!
1. Select delay/timeout (0-255 min.) from the table shown.
!
2. Enter in corresponding address locations above (left and right digits).
!
3. For a desired delay/timeout not listed do the following:
A. Choose a desired delay/timeout, ex: 20 min.
B. Divide it by 16
OUTPUT TIMEOUTS:
If a timeout of “0 min.” is selected, then the output
will remain active (ON) until the system is reset or disarmed. For UL Residential Installations, the
minimum timeout is 4 minutes. For UL Commercial Installations, the minimum timeout is 15
minutes.
[Default = blank (•) 1]
ADDRESS 2404
LEFT RIGHT
Pulse
Alarm
Output
Timeout
(min.)
[Default = blank (•) blank (•) ]
ADDRESS 2405
LEFT RIGHT
Fire
Output
Timeout
(min.)
[Default = blank (•) blank (•)]
ADDRESS 4083
LEFT RIGHT
Auto
Disarm
Rearm
Delay
(min.)
KEYPAD SYSTEM CODES (ADDRESS 0490, 0495 & 0500)
DEALER SECURITY CODE: Enter up to 6 digits to be used by the dealer to enter programming.
!
1. Enter in both left and right digits of address locations.
!
2. Valid entries are: 0-9.
Note:
If left blank, the Master Security Code must then be used to enter programming.
AMBUSH CODE: Enter a 2-digit code used just prior to disarming and will activate an Ambush Condition, causing a SILENT report to
be sent to the central station.
!
1. Enter in both left and right digits of address locations.
!
2. Valid entries are: 0-9.
Note:
Also, “Enable Keypad Ambush” (Address 2440-2446), “Report on Ambush Alarm” (Address 1125, 1127, 1135 & 1137) and
“Ambush Code” (Address 0900) must all be enabled.
[Default = blank (•) blank (•) from address 0490-0492]
Panel Access
Code
ADDRESS 0490-0492
0490 0491 0492
LRLRLR
PANEL ACCESS CODE: Enter up to 6 digits to activate a door strike while the area is disarmed.
!
1. Enter in both left and right digits of address locations.
!
2. Valid entries are: 0-9.
Note:
Also, “Access Control on Aux. Output” (Address 2418) and “Aux. Output Access Control Timeout” (Address 2402) must both be
enabled.
ADDRESS 0495
LEFT RIGHT
Ambush
Code
[Default = blank (•) blank (•)]
[Default = blank (•) blank (•) from address 0500-0502]
Dealer Security
Code
ADDRESS 0500-0502
0500 0501 0502
LRLRLR
System Delays/Timeouts & Keypad Codes
[Default = blank (•) blank (•)]
ADDRESS 4082
LEFT RIGHT
Report
Cancel
Window
(sec.)
1 Quotient Left Digit
16 20
16
4 Remainder Right Digit
To Next Page
