GEM-P3200 Programming Instructions
L
NAPCO Security Systems
WI818D 08/00
!
Page 42
ADDRESS 0910-0917
ZONES REPORT CODE (CONTROL PANEL)
ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8
0910 0911 0912 0913 0914 0915 0916 0917
LRLRLRLRLRLRLRLR
ADDRESS 0918-0921
ZONES REPORT CODE (GROUP 1)
ZONE 9 ZONE 10 ZONE 11 ZONE 12
0918 0919 0920 0921
LRLRLRLR
ADDRESS 0922-0925
ZONES REPORT CODE (GROUP 2)
ZONE 13 ZONE 14 ZONE 15 ZONE 16
0922 0923 0924 0925
LRLRLRLR
ADDRESS 0934-0937
ZONES REPORT CODE (GROUP 5)
ZONE 25 ZONE 26 ZONE 27 ZONE 28
0934 0935 0936 0937
LRLRLRLR
ADDRESS 0938-0941
ZONES REPORT CODE (GROUP 6)
ZONE 29 ZONE 30 ZONE 31 ZONE 32
0938 0939 0940 0941
LRLRLRLR
ADDRESS 0926-0929
ZONES REPORT CODE (GROUP 3)
ZONE 17 ZONE 18 ZONE 19 ZONE 20
0926 0927 0928 0929
LRLRLRLR
ADDRESS 0930-0933
ZONES REPORT CODE (GROUP 4)
ZONE 21 ZONE 22 ZONE 23 ZONE 24
0930 0931 0932 0933
LRLRLRLR
Default for Group Zone Report Codes depends on Easy Menu Question “RCVR.
7Gas Alarm
8 Heat Alarm
0 Auxiliary Alarm
B 24 Hour Auxiliary
DATA
ENTRIES
LEFT
1
2
3
4
MODEM CODE
Fire *
Panic
Burglary
Hold up
ZONE REPORT
CODE OPTIONS
DATA ENTRIES
LEFT RIGHT
NOTE:
Zones 1-8 are included in the control panel and Zones 9-48 are EZM Zones. See Address 2600-2605 to
enable “EZM Zone Groups”.
PULSE EVENT CODE will be the first digit of the 2 digit reporting code. the second digit will be the
second digit of the reporting zone. For example, for zone 9 (address 0918), if the right digit is “3", then
the reporting code is “39”. For example, for zone 15 (address 0924), if the right digit is “4", then the
reporting code is “45”.
MODEM CODES determine the zone types reported for the following formats: SIA and ADEMCO Point
ID.
!
1. Select the desired Modem Code for each zone from the table shown.
CS ZONE REPORTING CODES (ADDRESS 0910-0957)
ADDRESS 0950-0953
ZONES REPORT CODE (GROUP 9)
ZONE 41 ZONE 42 ZONE 43 ZONE 44
0950 0951 0952 0953
LRLRLRLR
ADDRESS 0954-0957
ZONES REPORT CODE (GROUP 10)
ZONE 45 ZONE 46 ZONE 47 ZONE 48
0954 0955 0956 0957
LRLRLRLR
ADDRESS 0942-0945
ZONES REPORT CODE (GROUP 7)
ZONE 33 ZONE 34 ZONE 35 ZONE 36
0942 0943 0944 0945
LRLRLRLR
ADDRESS 0946-0949
ZONES REPORT CODE (GROUP 8)
ZONE 37 ZONE 38 ZONE 39 ZONE 40
0946 0947 0948 0949
LRLRLRLR
CS Zone Reporting Codes
To Next Page
