GEM-P3200 Programming Instructions
L
NAPCO Security Systems
WI818D 08/00
!
Page 40
CS REPORTING CODES (ADDRESS 0859-0869)
ADDRESS
0864-0869
LEFT ADDR RIGHT
blank (•) 0864
blank (•) 0865
blank (•) 0866
blank (•) 0867
0868
0869
OPENING/CLOSING
REPORTING CODES
Closing
Conditional Closing
Opening
Opening after Alarm
Fail to Close
Fail to Open
ADDRESS
0860-0862
LEFT ADDR RIGHT
blank (•) 0859
blank (•) 0860
blank (•) 0861
blank (•) 0862
ALARM/TROUBLE
REPORTING CODES
Cancel
Alarm Restore
Trouble
Trouble Restore
[Default = blank (•) blank (•) from address 0859-0869]
CS REPORTING CODES:
!
1. Enter in corresponding address
location (left and right digits).
!
2. Valid entries are: 1-9, 0 and B-F.
NOTE:
Dark shaded data value box
shows option not available.
Default for CS Telco 1 Subscriber Event ID Number (Area 1) depends on Easy Menu Question “ACCOUNT #”. [Default = blank (•) blank (•) blank (•)
blank (•)] for all other ID Numbers.
CS TELCO SUBSCRIBER ID NUMBERS:
Enter the Subscriber Opening/Closing and Event ID Numbers for any of the 3 CS
Receivers.
!
1. Enter in corresponding right digit address location (left digit is not used).
!
2. Enter 3 or 4 digits (depending on the CS receiver format) for each subscriber number from left to right.
NOTE:
Leave trailing boxes blank (•).
!
3. Valid entries are: 0-9, 0 and B-F.
CS SUBSCRIBER ID NUMBERS (ADDRESS 0790-0857)
AREA 1
ADDRESS 0790-0793
(RIGHT DIGITS 1-4)
0790 0791 0792 0793
RRRR
CS TELCO 3 SUBSCRIBER OPENING/CLOSING ID NUMBERS
AREA 2
ADDRESS 0794-0797
(RIGHT DIGITS 1-4)
0794 0795 0796 0797
RRRR
AREA 1
ADDRESS 0822-0825
(RIGHT DIGITS 1-4)
0822 0823 0824 0825
RRRR
CS TELCO 3 SUBSCRIBER EVENT ID NUMBERS
AREA 2
ADDRESS 0826-0829
(RIGHT DIGITS 1-4)
0826 0827 0828 0829
RRRR
SYSTEM
ADDRESS 0854-0857
(RIGHT DIGITS 1-4)
0854 0855 0856 0857
RRRR
CS Subscriber ID Numbers (TELCO 3) & CS Reporting Codes
