GEM-P3200 Programming Instructions
L
NAPCO Security Systems
WI818D 08/00
!
Page 64
Compatibility Number
The compatibility number is a 4-digit security code that, if programmed into
both the control panel and each GEM-RP1CAe2 keypad, dedicates the
keypad to only that panel. That is, (a) similar keypads not having the
correct compatibility number will not operate in the system and (b) a
keypad may not be removed for use on a system with a different compatibility number. Press the
A
button to
continue or press the
C
button to exit.
EZM Address
The keypad's internal EZM (Expansion Zone Module) may be utilized to
provide four additional wired zones. Whether used alone or in conjunction
with optional GEM-EZM series modules or other keypad EZMs, it must be
assigned a unique address (or Group number, see Keypad Programming
Workbook) similar to its keypad address. If no other EZMs are to be used,
designate the keypad as Group “01” at the “
EZM ADDRESS 00
” display. In multiple-EZM systems, enter an assigned
group number “01” through “06”. (Each EZM must have a unique assigned group number, starting with “01” and
proceeding consecutively.) Press the
J
button. Press the
A
button to continue or press the
C
button to exit.
Zone Response
The normal loop response of each keypad expansion zone is 750mS,
however the response time of any zone can be reduced to 50mS as
follows.
1. Of the following, circle the number(s) in parentheses associated with the zone(s) to be changed:
Zone 1=(1); Zone 2=(2); Zone 3=(4); Zone 4=(8)
2. Add up the circled numbers.
3. At the keypad, enter the sum as a two-digit number “01” through “15” on the display, then press the
J
button.
Example. Change Zones 2, 3 and 4 to 50mS response.
1. Circle numbers for Zones 2, 3 and 4: (2), (4) and (8).
2. Add up the circled numbers: 2 + 4 + 8 = 14.
3. Enter “14” at the keypad, then press the
J
button.
Press the
A button to continue or press the C button to exit the Keypad Configuration Mode (display will read
“
01 OUT OF SYSTEM
”). Then replace Jumper JP5 across Pins 1–2 (top two).
NEW COMPAT# 0000
EZM ADDRESS 01
ZONE RESPONSE 00
Keypad Configuration Mode: Configuring the Keypads
