System Setup (cont.):
Line Outputs:
Connect the L and R Line Outputs (12) to the inputs of your PA mixer, amplifier or DAW
Drum Inputs:
Connect the L and R Drum Inputs (13) to the outputs of your e-drum module or sample player. The Mix control
(6) is used to regulate the balance between the input signal from the Drum Inputs (13) and the AE Cymbal
Inputs (17).
Headphone Output:
Connect a 3.5 mm Stereo headphone connector to this output. (Use 8 - 64 Ohm Headphones for best
performance.) The headphone output level is controlled by the Phones Volume control (8).
CAUTION: The Digital Cymbal Processor’s headphone amplifier is capable of driving many headphones
to very high sound levels. Use care in setting the headphone volume level control to avoid potential
hearing damage.
Aux Input:
Connect an MP3 player or other audio playback source to this input using 3.5 mm stereo connector.
The connected source will be mixed with the cymbal and Drum inputs in both the Line and headphone outputs.
USB:
For firmware or preset updates, connect a computer to this input using a standard USB cable.
11
