Rear Panel
Controls & Connectors Descriptions:
12. Line Outputs: L&R 1/4-inch mono unbalanced outputs. Connect these to the inputs of your PA system,
DAW, amplifier, etc. These outputs are a mix of the cymbal microphone, Drum, and Aux inputs.
13. Drum Inputs: L&R 1/4-inch mono unbalanced inputs. Connect the outputs of your e-drum module,
sampler, etc. to these inputs to mix them with your AE cymbals.
14. Standby / Power Switch: Switches between Standby, Power On and Lights On modes. To operate
the AE Cymbal System without illuminating the blue LED rings in the cymbal microphones,
select the middle (On) position. NOTE: In the Standby position the controller is actually “sleeping”
and draws a small amount of current. It can be safely left in this position indefinitely. In order to
completely shut the unit off the power adapter must be unplugged from the controller or disconnected
from its AC supply. In order to ensure that your user settings and customized Kit Presets are safely
stored in memory, it is recommended that you always switch the DCP to Standby mode before
physically disconnecting its power supply or switching off AC power on a plug strip.
15. Power Input: Connect the supplied power supply here. Use only the power supply provided with your
AE Digital Cymbal Processor.
16. USB Connector: Connect to a computer for firmware and presets updates.
17. AE Cymbal Pickup Inputs: Connect the color-coded cable ends of the AE Cymbal Pickup cable
snake to these inputs.
7
