Front Panel
Controls & Connectors Descriptions:
1. Channel Preset Control: Selects a tone-shaping preset for each of the five AE Cymbal input channels.
2. Illuminated Logo: The “Z” logo lights steadily while the DCP is operating. While the Standby/Power
switch (14) is in standby (“sleep”) mode it pulsates.
3. Cymbal Channel Pan: Pans the selected channel’s AE Cymbal output Left or Right.
4. Cymbal Channel Volume: Controls the mix level of the selected AE Cymbal channel.
5. Master Volume: Controls the volume of the Line Outputs (12) independently of the Headphone
Output (9) level.
6. Drum / Cym Mix: Controls the relative balance between AE Cymbals and Drum Inputs (13).
7. Reverb: Controls the level of reverb return for all AE Cymbals.
8. Phones Volume: Controls the level of headphone output (9) independently of Line Outputs (12).
9. Headphone Output: 3.5 mm Stereo connector. (Use 8 - 64 Ohm Headphones for best performance.)
Output level controlled by Phones Volume (8).
10. Aux Input: Connect an MP3 player or other audio source to play along with pre-recorded music.
The connected source will be mixed with the cymbal and Drum inputs in both the Line and
headphone outputs.
11. Channel Preset Display: Displays the currently selected preset for each of the five cymbals.
