MIDI Specifications:
The AE Digital Cymbal Processor incorporates a class-compliant MIDI-over-USB device port. No special device
drivers are required for either Mac OS or Windows. The USB port is used in conjunction with the AE Cymbals
DCP Access Tool application Program (available via download from the Gen16 tech support website) for uploading
firmware updates to the DCP.
Gen16 AE Digital Cymbal Processor MIDI Implementation Chart
Trans-
mitted
Recog-
nized
Description Remarks
Basic Channel 1 The base channel can be set to 1-8 via the Settings
Menu. The AE DCP uses 9 consecutive channels,
starting with the base channel.
Mode 4 no no
Note Number no no
Velocity no no
Aftertouch no no
Pitch Bend no no
Controller 0, 2-9, 11,
13-17, 19-
33,42-56,
61-62, 68-72,
76, 78-79,
81-84, 100
yes yes Proprietary
control
functions
Messages are sent on these controllers when presets
are changed and at other times. Used also by DCP
Access Tool program in controlling DCP parameters
remotely. Channels base channel - base channel+5
are used.
40 yes yes Cymbal
Channel Volume
Target cymbal = msg channel-base channel+1
(1=Hi-Hat, 2=Ride, etc.)
41 yes yes Cymbal
Channel Pan
Target cymbal = msg channel-base channel+1
(1=Hi-Hat, 2=Ride, etc.)
65 yes yes Headphone
Volume
TX on base channel, RX channel is ignored
66 yes yes Mix TX on base channel, RX channel is ignored
67 yes yes Reverb Return TX on base channel, RX channel is ignored
73 yes yes Master Volume TX on base channel, RX channel is ignored
74 yes yes Aux Input
volume
TX on base channel, RX channel is ignored
