Gen16 AE - MIDI Specifications: Program Change Messages

Gen16 AE Digital Cymbal Processor MIDI Implementation Chart
Program Change On Channel
(base channel
+ target cym-
bal[1-5] -1)
yes yes Cymbal Preset
Change
Transmit to DCP to change a preset, DCP transmits
when preset is changed via onboard buttons. Channel
determines target cymbal. For example, if Base Chan-
nel = 1, sending a Program Change message of value
4 on channel 2 sets the Ride preset to #4.
Max Value = Number of presets stored in the target
channel. Program change messages whose channel or
data is out of range are ignored.”
On Channel
(base channel
+ 5)
yes yes Reverb Preset
Change
Transmit to DCP to change a preset, DCP transmits
when preset is changed via onboard buttons. For
example, if Base Channel = 1, sending a Program
Change message of value 8 on channel 6 sets the
Reverb preset to #8.
Max Value = Number of reverb presets stored in the
DCP. Program change messages whose data is out of
range are ignored.
On Channel
(base channel
+ 6)
yes yes Recall Kit
Preset
Transmit to DCP to change a preset, DCP transmits
when preset is changed via onboard buttons. For ex-
ample, if Base Channel = 1, sending a program change
message on channel 7 with value 3 recalls Kit Preset
#3.
If value is 0 or greater than the highest Cym5 preset
number (i.e. the number of Kit Presets) the message is
ignored.”
MIDI Specifications (cont.):
30
