Gen16 AE - MIDI Specifications: Advanced MIDI

Gen16 AE Digital Cymbal Processor MIDI Implementation Chart
On Channel
(base channel
+ 7)
no yes Store Kit Preset The currently-displayed cymbal presets are saved
to the Kit Preset indicated by the Program Change
Message’s value. For example, if Base Channel = 1,
sending a program change message on channel 8 with
value 2 stores the currently-displayed cymbal presets
to Kit Preset #2.
If value is 0 or greater than the highest Cym5 preset
number (i.e. the number of Kit Presets) the message is
ignored.
On Channel
(base channel
+ 8)
no yes Pickup Light
Control
Send an odd number to turn the pickup lights on or
an even number to turn them off. For example, if Base
Channel = 1, sending a program change message on
channel 9 with value 3 turns the pickup lights on.
Sysex yes yes Proprietary
Internal Control
Used for firmware updates and production test.
System Common Real-time
Tune
no yes Proprietary
Internal Control
Used for firmware updates and production test.
Aux Messages no no
All MIDI messages not listed are unimplemented.
