Gendex DenOptix® QST
Figure 4-4 Panoramic and cephalometric imaging plates
Panoramic Cephalometric
1) Plastic mounting strips used to hold panoramic imaging plate onto the carousel
2) Active imaging area, white color
3) Patient left ( ) and right ( ) side indicators
4) General information that includes:
• Available from Gendex
• Date of manufacture
• Imaging plate size
• IP serial number
Rear (Black)
Front (Blue)
R
L
