Gendex Expert DC - Page 41

032-0207-EN Rev 0
5-7
Display on the
Quickset Tubehead
Control is not lit
correctly
Individual lights may or
may not be working
properly
Horizontal Arm J17 is
misconnected
Ensure that the arm
connections are
securely made, and
that the connectors are
neatly dressed into the
Horizontal Arm, with no
undue stress being
exerted on the wiring.
Horizontal Arm J21 is
misconnected
Ensure that the arm
connections are
securely made, and
that the connectors are
neatly dressed into the
Horizontal Arm, with no
undue stress being
exerted on the wiring.
Table 5-1 Common Symptoms and 
Possible Remedies (Continued)
Symptom Additional Symptoms Possible Cause Remedy
