032-0207-EN Rev 0
Logic Board - Connectors and Jumpers
5-19
(Continued)
Table 5-8 Logic Board (part no. 124-0293) Connectors
Designator Description
J8 Converter Board Interconnect
J9 Tubehead Interface PCB
J10 Interface Assembly (Master Control Touch Panel serial bus)
Table 5-9 Logic Board (part no. 124-0293) Jumpers
Designator Description
JP20 Negative Preheat Offset (must be open for normal
operation)
JP21 mA Feedback Loop (must be present for normal operation)
JP22 Positive Preheat Offset (must be open for normal operation)
JP23 Jumper Holder
To Next Page
