Gendex Expert DC Service Manual

032-0207-EN Rev 0
Opening the Master Control
1-7
(Continued)
5. Grip the outer cover at the top and at the bottom rear hand-grip cutout
and carefully pull it off.
Figure 1-9 Removing the Outer Cover
6. Lay the covers aside to be re-installed later.
7. Remove the two Phillips head screws and open the door carefully.
Figure 1-10 Opening the Door
