Genelec 4010A - Page 6

6 English
70
75
80
85
d
B
r
A
40
20k
70
100
200
500
1k 2k
5k
10k
Hz
Genelec Oy 4010 (dBr) vs freq (Hz) 10 Jan 13
65
70
75
80
65
BASS TILT
TREBLE TILT
Figure 4. The curves
show the effect of the
“Bass Tilt” and “Treble
Tilt” controls on the free
field response of the
4010A
70
75
80
85
d
B
r
A
40
20k
70
100
200
500
1k 2k
5k
10k
Hz
Genelec Oy 4010 (dBr) vs freq (Hz) 10 Jan 13
65
Figure 5. The upper
curve group shows
the horizontal directiv-
ity characteristics of the
4010A measured at 1 m.
The lower curve shows
the system's power re-
sponse.
