Genelec G Two User Manual

English 11
SYSTEM SPECIFICATIONS
Frequency response (–6 dB) 56 Hz - 25 kHz
Max. short term sine wave acoustic output on axis in half space, averaged 100 Hz - 3 kHz
at 1 m > 100 dB SPL
Maximum long term RMS acoustic output in same conditions with IEC weighted noise (limited by
driver unit protection circuit) at 1 m: > 93 dB SPL
Self generated noise level in free eld at 1 m on axis (A-weighted): < 5 dB
Harmonic distortion at 85 dB SPL at 1 m on axis 50...200 Hz < 3 %
>200 Hz < 0.5 %
Input connector type: 1 RCA female
Input impedance: 10 kOhm:
Crossover frequency, Bass/Treble: 3.0 kHz
Tabletop control operating range: -4 dB at 200 Hz
Bass control operating range in –2 dB steps: 0 to -6 dB at 100 Hz
Low Bass control operating range: -4 dB step at 65 Hz
Bass amplier power (long term output power is limited by driver unit protection circuitry) 50 W
Treble amplier power (long term output power is limited by driver unit protection circuitry): 50 W
Amplier system distortion at nominal output THD+N: < 0.05 %
Mains voltage: 100-240 V AC, 50-60 Hz
Voltage operating range: ±10 %
Power consumption
Standby (ISS active)
Idle
Full output
<0.5 W
3 W
60 W
Bass driver
Treble driver
105 mm (4 in)
19 mm (
3
/
4
in)
Weight: 3.2 kg (7 lbs)
Dimensions:
Height including Iso-Pod™ table stand
Height without Iso-Pod™ table stand
Width
Depth
242 mm (9
1
/
2
in)
230 mm (9
1
/
16
in)
151 mm (6 in)
142 mm (5
5
/
8
in)

Genelec G Two Specifications

General

Product color	White
Housing material	-
Recommended usage	Universal
Suitable for outdoor use	No
Tweeter	Yes
Speaker type	2-way
Speaker placement	Tabletop/bookshelf
Audio output channels	1.0 channels
Woofer diameter (imperial)	4 \
Tweeter diameter (imperial)	0.75 \
Impedance	- Ω
Sensitivity	95 dB
Frequency range	65 - 21000 Hz
RMS rated power	- W
Audio RCA inputs	1
Connectivity technology	Wired

Weight and Dimensions

Depth	142 mm
Width	151 mm
Height	242 mm
Weight	3700 g
