7
www.genelec.com www.genelec.com
1032A
SPL short term RMS at 1 m 113 dB
Peak SPL per pair with music 124 dB @ 1 m
Drivers Bass 10” + Treble 1”
metal dome + DCW
TM
Frequency response 42-21000 Hz ± 2.5 dB
Amplifier power per channel Bass 180 W + Treble 120 W
Dimensions H x W x D 495 x 320 x 290 mm,
(19½ x 12
5
/
8
x 11
7
/
16
”) with Iso-Pod
TM
Weight 21.7 kg (48 lb)
Order code 1032AP (durable black paint),
1032AE (black veneer)
The 1032A Two-Way Active Monitor
Originally designed as a near field monitor, the 1032A can also be
used for main monitoring in many situations due to its high output and
extended frequency response. It is magnetically shielded making it ideal
for recording studios, broadcast monitoring, TV control rooms, mobile
vans and CD/DVD mastering.
The 8130A Digital Monitoring System
The Genelec 8130A Digital Monitoring System has a 24
bit/96 kHz digital interface. With automated digital signal
detection it can both be fed with AES/EBU formatted digital
signal or analog line level audio signal. Due to its compact
size and integrated 8000 MDE
TM
construction, the 8130A is
ideal for near-field monitoring where ever space is limited,
as well as for use with computer soundcards and multimedia
applications. The digital signal can be forwarded through to
other units.
8130A
Digital input and word length AES/EBU 16...24 bits
Input sampling rate 29-200 kHz
SPL short term RMS at 1 m 100 dB
Peak per pair with music 108 dB @ 1 m
Drivers Bass 5” + Treble 3/4”
metal dome + DCW
TM
Frequency response 58-20000 Hz ± 2.0 dB
Amplifier power per channel Bass 40 W + Treble 40 W
Speaker dimensions H x W x D 299 x 189 x 178 mm
(11
13
/
16
x 7
7
/
16
x 7”) with Iso-Pod
TM
Speaker weight 5.6 kg (12.3 lb)
Order code 8130AP
