Please record the following information from the generator DATA DECAL or information decal.
1. Model Number _____________________ 2. Serial Number __________________
3. kW Rating _________________________ 4. Rated Voltage __________________
5. Phase _____________________________ 6. Hertz __________________________
7
9, 18
6
IF GENERATOR DOES NOT START, REMOVE
AND INSPECT FUSE.
(SEE OWNER'S MANUAL TROUBLE SHOOTING
GUIDE.)
PRESS PRIME SWITCH FOR 10 SECONDS BEFORE STARTING. WHEN STARTING, DO
NOT PRESS START BUTTON LONGER THEN 15 SECONDS PER ATTEMPT.
STOP
PRIME
CONTROL CENTER
7.5A
FUSE
START
FUEL
CIRCUIT
BREAKER
BREAKER
CIRCUIT
(OR ANNUALLY)
CHANGE EVERY 400 HOURS.
FUEL FILTER P/N:
PREFILTER P/N:
CONTACT THE GUARDIAN SERVICE LOCATOR AT 1-800-333-1322.
WHEN SERVICE OR PARTS ARE NEEDED IN THE USA OR CANADA,
SPARK PLUG P/N:
OIL FILTER P/N:
AIR FILTER P/N:
INSPECT & CLEAN
PLUGS EVERY 100 HOURS.
REPLACE PLUGS EVERY
500 HOURS. (IF NECESSARY)
CHECK DAILY
(SAE VISCOSITY)
1.8L/1.9QT
HOURS. (OR ANNUALLY)
SAE 30 OR 10W-30
5W-30 OR 5W-20
PERFORM MORE OFTEN IN DUSTY CONDITIONS
CHANGE EVERY 100
EVERY 250 HOURS.
REPLACE ELEMENT
EVERY 100 HOURS.
CLEAN PREFILTER
TEMPERATURE:
-20°F TO 40°F
40°F AND HIGHER
WITH FILTER:
OIL CAPACITY
OIL & OIL FILTER:
*
AIR FILTER:
REPLACEMENT
INFORMATION:
FUEL FILTER:
MAINTENANCE SCHEDULE
SPARK PLUGS:
OIL LEVEL:
*
*
*
SERVICE ACCESS PANEL
AIR FILTER LOCATED BEHIND PANEL.
0D4511
087769
072347
070185
0D9723
17
13
12
1
11, 15 (Behind Access Panel)
10
5
2
3
4
14
8
16
19
20
1.1 GENERATOR IDENTIFICATION
REFERENCE NUMBER IDENTIFICATION
1. Generator Air Intake Screen
2. Data Plate
3. Engine Start/Stop Switch
4. 7.5 amp Fuse
5. Circuit Breaker
6. Optional Remote Panel Receptacle
7. Generator AC Output Leads
8. Starter Contactor
9. Fuel Inlet
10. Fuel Primer Switch
11. Fuel Pump (Behind access panel.)
12. Oil Filter
13. Oil Drain Plug
14. Oil Dipstick and Filler Tube
15. Air Filter (Behind access panel.)
16. Spark Plugs
17. Exhaust Outlet
18. Fuel Filter
19. LP Fuel Inlet
20. Evaporative Port
General Information
