34
7. For all models except the 8 and 10 kW check to be sure that
voltage from the generator is correct. If line-to-line voltage
is not
approximately 240 volts, refer to the generator Owner’s
Manual
for the proper adjustment procedure. On all models, if line-to-
neutral voltage is not 120 volts, check the neutral connection
between the generator and load center.
8. For 8 kW models check to be sure that the frequency from
the generator is correct. If the frequency is not approximately
60Hz, refer to the generator Owner’s Manual for the proper
adjustment procedure.
9. Switch the generator’s main circuit breaker OFF and put the
mode switch in the OFF position to shut down the generator.
10. With utility power still OFF, switch the utility feed breaker
(below the transfer operator on the left side of the load center)
ON. This will also move the generator feed breaker to the OFF
position.
11. Switch the main utility breaker ON to restore utility power.
12. Switch the generator’s main breaker ON and put the mode
switch in AUTO.
13. Shut OFF utility power at the main utility breaker and make
sure the generator starts automatically.
14. Switch the main utility breaker to ON and make sure that power
on the lower half on the load center is automatically transferred
back to the utility. This can be verified by noting the position of
the utility feed and generator feed breakers.
