Generac Power Systems 14 kW LP

TRANSFER SWITCH
PART 3
Page 75
Section 3.3
Troubleshooting Flowcharts
TEST 28 – CHECK
FUSE F1 & F2
TEST 32 – CHECK
N1 & N2 WIRING
GOOD
GOOD
BAD
BAD
REPAIR OR REPLACE
WIRING
INSPECT/REPLACE
CONTROLLER
FINISH
Problem 9 – Blown F1 or F2 Fuse
TEST 29 – CHECK
FUSE F3 (T1)
TEST 36 – CHECK
T1 WIRING
GOOD
GOOD
BAD
BAD
REPAIR OR REPLACE
WIRING
REPLACE CONTROLLER
STOP TESTING
Problem 10 – Blown T1 Fuse
