22
7000EXL Extended Life Generator
PARTS LIST - ALTERNATOR & FRAME
Item Part # Qty Description
1 M187024GS 1 CRADLE
2 192982GS 1 SHIELD, Heat
3 92982GS 1 DECAL, Danger
4 92665GS 1 INSULATION
5 B1998GS 1 ASSY,Tank, Fuel (Includes Item 12)
6 B4363GS 1 CAP, with Gauge, Fuel
7 85000GS 1 CLIP, Insulation
8 93826GS 1 DECAL, Start Instructions
9 78831BGS 4 SCREW
10 83465GS 4 GROMMET,Tank
11 77395GS 8 NUT, Lock
12 192980GS 1 KIT,VLV, FUEL, SRV
14 B2153GS 8 SCREW
15 43116GS 4 SCREW
16 39287GS 2 SCREW
17 B4135GS 2 PIN, with Lanyard
18 187104GS 4 WASHER, Nylon
19 49820GS 2 NUT, Nylok
20 83083GS 1 SCREEN, Spark Arrestor
21 86307GS 4 SCREW
22 92247GS 1 HOUSING, Engine Adapter
23 M92531GS 1 SUPPORT, Engine
24 189160GS 12 NUT
25 22129GS 4 WASHER, Lock
26 82857GS 4 MOUNT,Vibration
27 22531GS 2 SCREW
28 92609GS 2 MOUNT,Vibration
29 22142GS 2 SCREW
30 A7433GS 1 MUFFLER
31 M92731GS 1 SUPPORT, Engine & Muffler
32 90239GS 1 GASKET, Muffler
33 B1342GGS 1 ASSY, Rotor
35 96796GS 1 WASHER
36 47481GS 1 SCREW
37 B1897AGS 1 ASSY, Stator
38 20566GS 1 DECAL, 1-800
39 40976GS 2 SCREW
40 92532GS 1 BRACKET, Muffler
41 66476GS 2 SCREW
42 186747GS 1 DECAL, Control Panel
43 92630GS 1 ASSY, Control Panel
44 192983GS 1 SHIELD, Heat
45 14353621GS 1 WIRE, Ground
46 26850GS 2 WASHER
47 BB3061GS 2 BOTTLE, Oil
48 81917GS 1 PIN, Roll
49 B4986GS 1 DECAL, Ground
50 186798GS 2 DECAL, Heat Shield
51 56893GS 5 SCREW
52 84132GS 1 ASSY, Power Regulator
53 67022GS 1 GROMMET, Rubber
Item Part # Qty Description
54 SRV66825DGS 1 CARRIER, Rear Bearing
55 86494GS 1 SCREW,Wing
56 23762GS 3 WASHER
57 66386GS 1 ASSY, Brush Holder
58 66849GS 2 SCREW
59 B4871GS 1 COVER, Bearing Carrier
60 74908GS 4 SCREW
61 B4605GS 2 GRIP
62 66849CGS 1 SCREW
63 65795GS 2 RECTIFIER, Battery Charge
64 66449LGS 4 BOLT, Stator
65 22145GS 4 WASHER
66 22097GS 6 WASHER, Lock
67 186744GS 1 MANUAL, Owners
68 BB5586GS 2 HANDLE (Includes Item 61)
69 52858GS 2 NUT, Lock
73 191267GGS 1 AXLE
74 B4966GS 2 WHEEL
75 22247GS 2 WASHER
76 191265GS 2 E-RING
77 189302BGS 1 ASSY,Wire
78 77282GS 1 SWITCH, Starter
79 188987GS 1 BRACKET, Switch
80 188989GS 1 ASSY, Jack, DC
81 22287GS 2 SCREW
83 22127GS 2 NUT
84 192985GS 1 TRAY, Battery
85 B4489GS 1 BATTERY
86 189302CGS 1 ASSY,Wire
87 185939HGS 1 ASSY,Wire
88 73054GS 1 DECAL, Fuel Shut-Off
89 77816GS 1 DECAL, Hot Muffler
90 39253GS 2 SCREW
91 A8927GS 1 MANUAL, Engine
92 52618GS 2 SCREW
93 23897GS 2 WASHER
94 52856GS 2 NUT
96 191698GS 1 ASSY,Wire
97 58359GS 1 LUG
98 189198GS 1 DECAL, Instruction, ES
99 B4177GS 1 CHARGE, Battery Float
100 189208GS 3 STABILIZER, Fuel
101 65787GS 1 CABLE, Battery Charge
102 37806GS 1 PLUG, 120V/30A
103 188971GS 1 PANEL, Extenda
104 22155GS 1 WASHER, Lock
105 49813GS 1 NUT
106 22259GS 2 NUT
108 189956GS 1 ASSY,Wheel Support
109 86292GS 1 SCREW
900 NSP 1 ENGINE
