SECTION 14: SPECIFICATIONS
TORQUE SPECIFICATIONS
Alternator (to cylinder) 10.0 Nm (7.4 ft. lbs.)
Air Cleaner Support Bracket 5.4 Nm (48 in. lbs.)
Armature 10.0 Nm (7.4 ft. lbs.)
Back Plate 4.5 Nm (40 in. lbs.)
Blower Housing 4.5 Nm (40 in. lbs.)
Breather 4.5 Nm (40 in. lbs.)
Carburetor (to manifold) 5.4 Nm (48 in. lbs.)
Connecting Rod 24.4 Nm (18 ft. lbs.)
Crankcase Cover 47.5 Nm (35 ft. lbs.)
Cylinder Head Bolts 29.9 Nm (22 ft. lbs.)
Cylinder Wrappers:
– M5 bolt 2.8 Nm (25 in. lbs.)
– M6 bolt 4.5 Nm (40 in. lbs.)
Exhaust Manifold 19 Nm (14 ft. lbs.)
Fan Retainer 21.7 Nm (192 in. lbs.)
Finger Guard:
– Hex Head Screws 4.5 Nm (40 in. lbs.)
– Finger Screws 1.3 Nm (12 in. lbs.) (Approximately)
Flywheel Nut 204 Nm (150 ft. lbs.)
Governor Lever (clinching screw) 11.3 Nm (100 in. lbs.)
Intake Manifold 19 Nm (14 ft. lbs.)
Oil Pump 12.2 Nm (9 ft. lbs.)
Rocker Arm Jam Nut 19 Nm (14 ft. lbs.)
Rotating Screen Screws 1.9 Nm (17 in. lbs.)
Spark Plug 19 Nm (14 ft. lbs.)
Starter Motor 24.4 Nm (18 ft. lbs.)
Valve Cover 6.8 Nm (5 ft. lbs.)
