Owner’s Manual for Mobile Generator 35
Operation
IMPORTANT NOTE: Always remain aware of people
and objects around the work site when moving or
lifting the unit.
3. See Figure 3-13. Use the unit lift point (A)
according to guidelines below.
Figure 3-13. Unit Lift Point
• Attach slings, chains, or hooks directly to the
central lift point (A).
NOTE: This unit is not equipped with forklift pockets.
Tying Down the Unit
When securing the unit for transportation, verify the
equipment being used to fasten the unit is in good
condition and has sufficient strength to hold the unit in
place during transport.
See Figure 3-14. The unit is equipped with four tie-down
points—two on each side (A).
Figure 3-14. Tie-Down Points
011188
A
011199
A
