Owner’s Manual for Mobile Light Tower 7
Introduction and Safety
Safety and Operating Decals
See Figure 1-1 through Figure 1-3. This unit features
numerous safety and operating decals. These decals
provide important operating instructions and warn of
dangers and hazards. The following diagrams illustrate
decal locations and descriptions.
Replace any missing or hard-to-read decals and use care
when washing or cleaning the unit. Decal part numbers
can be found in the parts manual at
www.generacmobileproducts.com.
ID Description ID Description
1 Setup and Take-Down Instructions (Electric) 16 Control Panel Label (not shown)
2 Setup and Take-Down Instructions (Manual) 17 Neutral Bonded to Frame
3 Danger—Overhead Power Lines 18 Not A Step
4 Warning—Electrical Storms and High Wind 19 Warning—High Temperature: Do Not Remove Guard
5 Owner’s Manual Location 20 Mast Junction Box Wiring (inside)
6 Electric Shock Hazard 21 Warning—Do Not Retract Outriggers With Tower Up
7 Warning—Hot Surface 22 Stowed Position
8 Warning—Pressurized Liquid 23 Lifting Point
9 Warning—Entanglement Hazard 24 Forklift and Tie-Down Point
10 Warning—Cutting Hazard 25 Engine Operation
11 Disconnect Battery Before Servicing 26 Ultra Low Sulfur Diesel Fuel Only
12 Danger—Carbon Monoxide 27 Danger—Fuel and Fueling Hazards
13 Electrical Ground Connection 28 Tie-Down Point
14 Danger—Winch Operation 29 Towing Instructions
15 Warning—Diesel Exhaust
