4 Owner’s Manual for Power Zone Connectivity Server
General Information
Specifications
NOTE: The Ethernet, RS-485, and USB cables should not be run in the same conduit or in the same wire grouping as
any high voltage or high current conductors.
NOTE: The RS-485 settings such as baud rate should be selected to be compatible with other components that are
connected to the RS-485 bus.
* Use Extension Kit (part no. A0000310806) to connect Power Zone Pro Main Controller to Connectivity Server when
Connectivity Server is mounted outside the generator enclosure.
Environmental Specifications
Operating Temperature -4 °F (-20 °C) to 140 °F (60 °C)
Humidity 5% to 90% non-condensing
Sealing IP65 rated
Enclosure UL Type 3R
Weight 0.5 lbs
Power Supply Requirements
Power Supply Voltage 11 to 13 V (12 V nominal)
Power Supply Usage 1.1 A (maximum during power up)
Power Supply Cable 2 wires - 16 AWG recommended
Communication (Ethernet)
Number of Ports 1
Communication Link 4 wires minimum of 8 pin connector - 2 wire Receive and 2 wire Transmit
Communication Cable Cat5e – 2 twisted pairs
Maximum Cable Length 328 ft (100 m)
Baud Rate Auto-Detect 10/100 Mbps
Communication (RS-485)
Number of Ports 1
Communication Link 2 wires
Communication Cable 2 wires - shielded twisted pair (i.e. Belden 3105A)
Maximum Cable Length 4,000 ft (1,219 m)
Baud Rate 115.2 kbps
Maximum Number of Devices 32
Protocol/Device Type Modbus/Master
Communication (USB)
Number of Ports 1
Connector Type A
USB version USB 1.1/2.0
Maximum Cable Length 16.5 ft (5 m)
Baud Rate 12 Mbps, 480 Mbps
Communication (Wi-Fi and Bluetooth)
Supported Antenna Type 2.4 Ghz Wi-Fi/Bluetooth
Wi-Fi 802.11 b/g/n (2.4 Ghz)
Bluetooth 4.1
Antenna (Wi-Fi and Bluetooth)
Type Internal on-board chip antenna
Frequency Band 2.4 Ghz
Gain 1.5 dBi max (2.4 Ghz)
Distance 20 ft (6.1 m) inside generator enclosure, 200 ft (61.0 m) outside generator enclosure*
LED
Number of LEDs 2
Color Red and green
