Unpacking and Inspection
Installation Guidelines for 50 Hz PowerPact™ 9
Parts Shipped Loose
Parts shipped loose are located in a clear plastic bag
inside the unit, in front of the engine or under the
alternator. The flex fuel line (A) is tied to either the battery
wires or the alternator can.
• Flex Fuel Line (A)
• Battery Terminal Cap (B)
• LP Fuel Jet (C)
• Fuel Jet O-ring (D)
• Decal - Service Entrance (Not Shown)
• Decal - Warning (Not Shown)
• MLCB Terminal Caps (E)
• Owner’s and Installation Manual (Not Shown)
• Battery Bracket (F)
• M6 x 1 16mm Thread Forming Screw (for Battery
Bracket) (G)
• 2 sets of Bolts, Nuts and Washers (for connecting
battery cables) (H)
Figure 2-3. Parts Shipped Loose
