13
10A, 12VDC BATTERY CHARGER
Nominal Input AC Line Voltage ........................ 120Vac
Operating AC Line Voltage Range ......108Vac to 132Vac
Input AC Line Frequency .............................50 or 60Hz
AC Line Fuse ...................................... 5 Amp, 5x20mm,
Littelfuse P/N 218005
Battery Fuse ..............................15 Amp, Littelfuse ATO
Blade P/N 257015
Nominal Charge Rate ..................................... 10 Amps
Equalize Voltage (typ) ....................................13.8 Volts
Float Voltage (typ) .........................................13.0 Volts
Current at Equalize to Float Transition (typ) .. 5 Amps
Battery Undervoltage Shutdown (typ) ...............11 Volts
LED Indicators
AC Line Voltage > 108Vac ...............Green LED ON
Battery Connected & Charging ........Yellow LED ON
the Green LED must be ON to obtain a valid
battery charging indication,
Yellow LED ON if charge current > approx 2
Amps)
Battery Current Drain (AC Power OFF) ....... 30mA (typ)
AC Line Connections ......................... via terminal block
(AC Hot, AC Neut & GND)
Battery Connections .......................... via terminal block
(Pos +, Neg -)
Control Connections ......................AC Power Fail Relay,
Form C, 2Amps, 12Vdc
(N.O. Contact closes when ac line voltage is applied)
(N.O. Contact opens when ac line voltage is removed)
î
