Genesis G80 - Engine Compartment

2-7
02
The actual engine compartment in the vehicle may differ from the illustration.
ORG3090001
1. Windshield washer fluid reservoir ...... 9-22
2. Jumper negative (chassis) terminal ..... 8-5
3. Fuse box ...............................................9-49
4. Radiator cap .......................................... 9-19
5. Engine coolant reservoir ......................9-18
6. Air cleaner ............................................ 9-23
7. Liquid-cooled intercooler
coolant reservoir ................................... 9-18
8. Brake fluid reservoir .............................9-21
9. Engine oil dipstick ................................9-16
10. Engine oil filler cap ............................... 9-17
ENGINE COMPARTMENT
