09
9-47
Instrument panel fuse panel
Fuse Name Fuse Rating Circuit Protected
MODULE9
10A
Overhead Console, AMP, Smart Phone Wireless Charger,
Low DC-DC Converter (AUX/AMP), Data Link Connector,
Driver/Passenger Power Seat Module, Electro Chromic
Mirror, Front/Rear A/C controller, Rear Seat Console
Remote Control Switch Switch, A/V & Navigation Head
Unit, A/C Control Module, Rear Seat LH/RH Heater Unit
SUNROOF
25A Sunroof Control Unit (Master/Slave)
MODULE11
10A
Head Lamp LH, Head Lamp RH, Multifunction Switch,
ADAS Unit (Parking)
MODULE12
10A IAU, IBU
A/C3
10A
E/R SUB Junction Block(Blower Relay), Incar Temperature
Sensor, A/C Control Module, Front A/C controller, Rear A/C
controller
A/BAG IND
10A Instrument Cluster, Overhead Console
E-SHIFTER2
10A Electronic ATM Shift Lever Dial
SPARE(IG2)
10A Not Used
MODULE10
10A ICU Junction Block (ESU)
MODULE7
10A
Driver Door Module, IBU, Multifunction Switch, IAU, Stop
Lamp Switch
MULTI MEDIA
10A Low DC-DC Converter
MODULE13
10A
Front/Rear A/C controller, Rain Sensor, Head-Up Display,
Security Indicator, A/C Control Module, Rear Occupant
Alert (ROA) Sensor, PTL Unit, Driver/Passenger Power
Outside Mirror, Driver/Passenger Power Seat Module,
Driver/Passenger Power Seat Switch, Driver/Passenger
Lumbar Support Unit(3/5/7CELL)
CLUSTER
10A Instrument Cluster, Head-Up Display
IBU2
10A IBU
AIR BAG2
15A SRS Control Module, Passenger Occupant Detection Sensor
PRESAFETY
SEAT BELT3
10A Pre-Active Seat Belt Unit
