Maintenance
9-50
Engine compartment fuse panel
Type Fuse Name Fuse Rating Circuit Protected
MAIN
ALT
225A Alternator
MDPS1
125A MDPS Unit
MULTI
COOLING FAN
100A Cooling Fan Motor
GLOW
100A Not Used
IEB1
60A IEB Unit
IEB2
60A IEB Unit
OIL PUMP
50A Electronic Oil Pump
IEB3
50A IEB Unit
REAR HEATED
40A Rear Heated Relay
E-CVVT1
40A E-CVVT Relay
4WD
30A 4WD ECU
WIPER
30A Wiper Motor
SB
HEAD LAMP LH
30A Head Lamp LH
START
30A Start Relay
HEAD LAMP
RH
30A Head Lamp RH
MICRO
A/C
15A A/C Relay
HORN
15A PCB Block(Horn Relay)
HTD IND
10A Front A/C controller
E-CVVT2
20A ECM
E-CVVT3
20A ECM
MODULE1
10A Not Used
FUEL PUMP
20A Fuel Pump Relay
ECU1
15A ECM
TCU1
20A TCM
