09
9-53
Engine compartment fuse panel
Type Fuse Name Fuse Rating Circuit Protected
MULTI
FUEL HEATER
40A Not Used
PTC HEATER1
50A Not Used
PTC HEATER2
50A Not Used
PTC HEATER3
50A Not Used
SB BLOWER
40A Blower Relay
MICRO
LDC
10A
Front Radar LH/RH, Rear Radar LH/RH,
Smart Phone Wireless Charger, Head-Up
Display,
Instrument Cluster, Front/Rear A/C controller,
Rear Seat Console Remote Control Switch
Switch,
Front Console Keyboard
A/C
10A A/C Control Module
To Next Page
