Genesis G80 - Page 570

09
9-55
Rear junction block
Fuse Name
Fuse
Rating
Circuit Protected
B+4 50A
ICU Junction Block(Fuse(P/Seat PASS2, Module4, Sunroof,
Door Lock, Trunk))
B+2 30A
ICU Junction Block(Fuse(IBU1, E-Shifter1, Spare(B+),
Module5, Air Bag1), IPS2, IPS5)
B+1 50A
ICU Junction Block(Fuse(Brake Switch)),
IPS1, IPS3, IPS4, IPS7, Long/Short Term Load Latch Relay
B+3 50A
ICU Junction Block(Fuse(P/Window LH, S/Heater DRV,
S/Heater PASS, P/Seat DRV1, P/Seat DRV2, P/Seat PASS1,
Curtain, Power Handle, P/Seat))
DCU3 20A Not Used
DCU4 10A Not Used
CHILD LOCK 15A Child Lock/Unlock Relay
DCU1 20A Not Used
P/WINDOW RH 30A
Passenger Power Window Module, Rear Power Window
Module RH
DCU2 20A Not Used
AMP 25A Low DC-DC Converter (AMP)
P/DOOR RR LH 15A Rear Door Latch LH
P/DOOR PASS 15A Passenger Door Latch
PRESAFETY SEAT
BELT1
30A Pre-Active Seat Belt Unit
P/DOOR RR RH 15A Rear Door Latch RH
ECS 15A ECS Unit
P/DOOR DRV 15A Driver Door Latch
PRESAFETY SEAT
BELT2
30A Pre-Active Seat Belt Unit
P/SEAT RR 20A Not Used
S/HEATER RR LH 20A Rear Seat LH Heater Unit
POWER TRUNK 30A PTL Unit (Power Trunk Lid)
S/HEATER RR RH 20A Rear Seat RH Heater Unit
